MJ-19009A/B/C/D High Quality Street Light Fixture With 60-200W LED

Short Description:

1. The overall design is novel, exquisite in appearance, generous and elegant;
2. Die-cast aluminum material, surface with plastic sprayed, with good anti-corrosion performance;
3. Exquisite structure waterproof design, protection level up to IP66;
4. A light controller can be installed to facilitate light control and other intelligent controls;
5. The special design of the lamp cavity saves space and reduces material costs;
6. With movable handle, the installation angle can be adjusted from 0-90°; the lamp housing can be opened manually, and the power will be automatically cut off, which is convenient for maintenance;
7. Using LUMILEDS SMD3030 or SMD5050 light source, and high-performance constant current drive, the overall performance is stable, high luminous efficiency, low luminous attenuation, and long service life.


Product Detail

Product Tags

Product Details

MJ-19009-street-light-fixture-details-1
MJ-19009-street-light-fixture-details-2

Product Size

MJ-19009-street-light-fixture-size

Product Parameters

Product Code MJ19009A MJ19009B MJ19009C MJ19009D
Power 60W-80W 90W-120W 120W-150W 160W-200W
CCT 3000K-6500K 3000K-6500K 3000K-6500K 3000K-6500K
Photosynthetic Efficiency around 120lm/W around 120lm/W around 120lm/W around 120lm/W
IK 08 08 08 08
IP 65 65 65 65
Working Temperature -45°-50° -45°-50° -45°-50° -45°-50°
Working Humidity 10%-90% 10%-90% 10%-90% 10%-90%
Input Voltage AC90V-305V AC90V-305V AC90V-305V AC90V-305V
CRI >70 >70 >70 >70
PF >0.95 >0.95 >0.95 >0.95
Installation Diameter Dia60mm/50mm Dia60mm/50mm Dia60mm/50mm Dia60mm/50mm
Product size 650*300*108mm 650*300*108mm 760*300*108mm 760*300*108mm

FAQ

1. What are your prices?

Our prices are subject to change depending on supply and other market factors. We will send you an updated price list after your company contact us for further information.

2. What’s your MOQ?

No MOQ required, sample checking provided.

3. How long is the sample production time?

Normally around 5-7 work days, except for special cases.

4. Can you provide customized services?

Yes, we can provide one-stop solutions, such as ODM/OEM, lighting solution.

5. What is your terms of payment?

We accept T/T, irrevocable L/C at sight usually. For regular orders, 30% deposit, balance before loading.
